Deep dive into Megarac SP image
Разбираем дамп Megarac SP по кусочкам
🚧Under construction🚧
Проверено на megarac с такими код бейзами:
FW_VERSION=2.02.76714
FW_DATE=Aug 8 2022
FW_DESC=RR10 AST2500 KERN3 BUILD 2
FW_RELEASEID=RR9
FW_CODEBASEVERSION=3.X
FW_VERSION=3.24.4421
FW_DATE=Dec 19 2016
FW_DESC=RR8 AST2400 HWENC BUILD 2
Theory
Весь дамп состоит из страниц (erasesize) по 0x10000. Может есть и другой, но не было замечено на практике, точно можно определить размер посмотрев в /sys/class/mtd/mtdX/erasesize, но об этом будет позже.
FMH
Каждая страница может содержать в начале или в конце FMH структуру. Если FMH в конце aka FMHTailed, то это указатель на полноценный FMH который можнт быть уже в любом месте страницы кроме старта. FMH содержит всю информацию по модулю (начало, размер, тип).
Разобрав эти структуры можно в общем уже разобрать дамп на partiotions, но без внутренних деталей. Обычно этого уже достаточно и даёт НА МНОГО более релевантные данные в отличие от binwalk который к примеру склеивает последовательные jffs в один.
Flashing sectors
Для более глубокого понимания что, как и куда монтируется нужна уже рабочая борда с доступом к sh.
Инфомацию можно собрать из:
dmesg- разметка (дублирует в большей части данные из FMH)/sys/class/mtd/mtd*/erasesize- узнатьerasesize/proc/sys/ractrends/Helper/*- узнать адрес где лежатuboot env
dmesg
В dmesg ядра лежит разметка флешки на блоки и обычно дублирует то что можно и так достать из FMH
/proc/sys/ractrends/Helper/*
Это то чем руководствуется флешер что бы не стереть ифнормацию по типу MAC адресов при обновлении прошивки BMC
/proc/sys/ractrends/Helper/FlashSize- полный размер флеша/proc/sys/ractrends/Helper/FlashStart- место в памяти с которого начинается флешка. То есть реальный0x10адрес флешки будет виден какFlashStart + 0x10/proc/sys/ractrends/Helper/FlashSectorSize- тот самый размер страницы который было бы не плохо знать на этапе парсинга FMH, но он как правило65536(0x10000)/proc/sys/ractrends/Helper/EnvStart- адрес в памяти начала UBoot env vars/proc/sys/ractrends/Helper/EnvSize- размер UBoot env vars (как правило одна страница флеша)
Practice
Пришло время на практике раздербанить дамп на кусочки. Повсеместно будет использован самописный комбайн uefi-mod-tools. Все операции производятся в linux.
По ходу дела наша задача собрать partitions.json в формате:
partitions.json
{
"partitions": [
{
"fileName": "section.bin", <- extract to file
"beginAddress": "0x00000000", <- begin
"endAddress": "0x00040000", <- end
... any other props will be ignored
}
... other partitions
]
}
Снимаем дамп
Дамп можно снять прищёпкой, софтверно через lxflash (ASPEED iRMP SOC Flash), как то софтверно через flasher из sh BMC (на практике не делалось).
📄️ ASPEED iRMP SOC Flash
Service tool for flash/backup ASTxxxx.
server host OS
$ sudo ./socflash.sh of=backup_rd450x_pve2_04-01-26.bin
ASPEED SOC Flash Utility v.1.20.00
Warning:
SoCflash utility is only for engineers to update the firmware in lab,
it is not a commercialized software product,
ASPEED has not done compatibility/reliability stress test for SoCflash.
Please do not use this utility for any mass production purpose.
Press y to continue if you are agree ....
y
Find ASPEED Device 1a03:2000 on 5:0.0
MMIO Virtual Address: c9dd1000
Relocate IO Base: 5000
Found ASPEED Device 1a03:2400 rev. 30
Static Memory Controller Information:
CS0 Flash Type is SPI
CS1 Flash Type is SPI
CS2 Flash Type is NOR
CS3 Flash Type is NOR
CS4 Flash Type is NOR
Boot CS is 0
Option Information:
CS: 0
Flash Type: SPI
[Warning] Don't AC OFF or Reboot System During BMC Firmware Update!!
[SOCFLASH] Flash ID : 1920c2
Find Flash Chip #1: MXIC MX25L256/257
Backup Flash Chip O.K.
Сканим FMH
$ uefi-mod-tools ami bmc-fmh-scan -i backup_rd450x_pve2_04-01-26.bin
[23:09:54 INF] Reading data from backup_rd450x_pve2_04-01-26.bin
[23:09:54 INF] Found FMH tail in 0x0000FFF0-0x00010000 that pointing to 0x0000FF80
[23:09:54 INF] Found FMH in 0x0000FF80-0x0000FFC0 that pointing to module boot 0x00000000-0x0002F198
[23:09:54 INF] Found FMH in 0x00040000-0x00040040 that pointing to module conf 0x00050000-0x000C0000
[23:09:54 INF] Found FMH in 0x000C0000-0x000C0040 that pointing to module conf 0x000D0000-0x00140000
[23:09:54 INF] Found FMH in 0x00140000-0x00140040 that pointing to module root 0x00150000-0x01252040
[23:09:54 INF] Found FMH in 0x01260000-0x01260040 that pointing to module osimage 0x01260040-0x0143A02C
[23:09:54 INF] Found FMH in 0x01440000-0x01440040 that pointing to module www 0x01450000-0x01670000
[23:09:54 INF] Found FMH in 0x01FF0000-0x01FF0040 that pointing to module ast2400e 0x01FF0040-0x01FF00B4
[23:09:54 INF] Writing output to console
[
{
"Type": "FMH-end",
"beginAddress": "0x0000FFF0",
"endAddress": "0x00010000",
"pointingToAddress": "0x0000FF80"
},
{
"Type": "FMH",
"beginAddress": "0x0000FF80",
"endAddress": "0x0000FFC0",
"moduleBeginAddress": "0x00000000",
"moduleEndAddress": "0x0002F198",
"moduleName": "boot"
},
{
"Type": "FMH",
"beginAddress": "0x00040000",
"endAddress": "0x00040040",
"moduleBeginAddress": "0x00050000",
"moduleEndAddress": "0x000C0000",
"moduleName": "conf"
},
{
"Type": "FMH",
"beginAddress": "0x000C0000",
"endAddress": "0x000C0040",
"moduleBeginAddress": "0x000D0000",
"moduleEndAddress": "0x00140000",
"moduleName": "conf"
},
{
"Type": "FMH",
"beginAddress": "0x00140000",
"endAddress": "0x00140040",
"moduleBeginAddress": "0x00150000",
"moduleEndAddress": "0x01252040",
"moduleName": "root"
},
{
"Type": "FMH",
"beginAddress": "0x01260000",
"endAddress": "0x01260040",
"moduleBeginAddress": "0x01260040",
"moduleEndAddress": "0x0143A02C",
"moduleName": "osimage"
},
{
"Type": "FMH",
"beginAddress": "0x01440000",
"endAddress": "0x01440040",
"moduleBeginAddress": "0x01450000",
"moduleEndAddress": "0x01670000",
"moduleName": "www"
},
{
"Type": "FMH",
"beginAddress": "0x01FF0000",
"endAddress": "0x01FF0040",
"moduleBeginAddress": "0x01FF0040",
"moduleEndAddress": "0x01FF00B4",
"moduleName": "ast2400e"
}
]
И перевариваем в partitions.json
partitions.json
{
"partitions": [
{
"fileName": "10-boot.bin",
"beginAddress": "0x00000000",
"endAddress": "0x0002F198"
},
{
"fileName": "20-conf.bin",
"beginAddress": "0x00050000",
"endAddress": "0x000C0000"
},
{
"fileName": "30-conf.bin",
"beginAddress": "0x000D0000",
"endAddress": "0x00140000"
},
{
"fileName": "40-root.bin",
"beginAddress": "0x00150000",
"endAddress": "0x01252040"
},
{
"fileName": "40-osimage.bin",
"beginAddress": "0x01260040",
"endAddress": "0x0143A02C"
},
{
"fileName": "50-www.bin",
"beginAddress": "0x01450000",
"endAddress": "0x01670000"
},
{
"fileName": "60-ast2400e.bin",
"beginAddress": "0x01FF0040",
"endAddress": "0x01FF00B4"
}
]
}
Обогащение данными из sh
Идём по ssh в BMC и достаём оттуда больше данных. Как получить рутовый шелл: bak2shell.
Чекаем что разметка из пункта выше сходится (BMC sh)
$ dmesg
....
<4>*PartCount is 0
<4>MTD Partition 0 : fullpart @ 0x0 of Size 0x2000000
<4>MTD Partition 1 : conf @ 0x50000 of Size 0x70000
<4>MTD Partition 2 : conf @ 0xd0000 of Size 0x70000
<4>MTD Partition 3 : root @ 0x150000 of Size 0x1110000
<4>MTD Partition 4 : www @ 0x1450000 of Size 0x220000
<5>Creating 5 MTD partitions on "Ractrends":
<5>0x00000000-0x02000000 : "fullpart"
<5>0x00050000-0x000c0000 : "conf"
<5>0x000d0000-0x00140000 : "conf"
<5>0x00150000-0x01260000 : "root"
<5>0x01450000-0x01670000 : "www"
В общем и целом всё ок не считая выравнивания по странице, FMH в приоритете
Смотрим маунты (BMC sh)
# cat /proc/cmdline
root=/dev/ramdisk ro ip=none ramdisk_blocksize=4096 mem=210M console=ttyS4,38400 rootfstype=cramfs bigphysarea=6144 imagebooted=1
$ mount
rootfs on / type rootfs (rw)
/dev/root on / type cramfs (ro)
/dev/proc on /proc type proc (rw)
sys on /sys type sysfs (rw)
/dev/shm on /var type tmpfs (rw)
devpts on /dev/pts type devpts (rw,gid=5,mode=620)
/dev/mtdblock1 on /conf type jffs2 (rw)
/dev/mtdblock2 on /bkupconf type jffs2 (rw)
/dev/mtdblock4 on /usr/local/www type cramfs (ro)
note
В некоторых версиях / маунтится как /dev/ramdisk, но по факту это 0x00150000-0x01260000 : "root"
Собирая всё что выше воедино получается:
| range | mtd | name | mount |
|---|---|---|---|
0x00150000-0x01260000 | mtdblock3 | root | / |
0x00050000-0x000c0000 | mtdblock1 | conf | /conf |
0x000d0000-0x00140000 | mtdblock2 | conf | /bkupconf |
0x01450000-0x01670000 | mtdblock4 | conf | /usr/local/www |
Инфо о UBoot env (BMC sh)
$ # Base addr
$ echo $(( ($(cat /proc/sys/ractrends/Helper/EnvStart) - $(cat /proc/sys/ractrends/Helper/FlashStart)) ))
196608
# Len
$ cat /proc/sys/ractrends/Helper/EnvSize
65536
Итого 0x30000-0x40000
Альтернативный способ найти UBoot env
Способ не 100%, но если вендор не стал придумывать каких то маразм схем, то подойдёт вариант с последовательным сканом всех страниц и проверкой CRC32, если совпало, то совпало :/
$ uefi-mod-tools uboot env-scan -i backup_rd450x_pve2_04-01-26.bin -o -
[00:12:57 INF] Reading data from backup_rd450x_pve2_04-01-26.bin
[00:12:57 INF] CRC32 hash matched
[00:12:57 INF] Read 15 pairs
[00:12:57 INF] Found potential env section in page 0x00030000-0x00040000
[00:12:57 INF] Writing output to console
{
"foundEnvPages": [
{
"variables": {
"bootcmd": "bootfmh",
"bootdelay": "3",
"baudrate": "0x9600",
"loads_echo": "1",
"autoload": "no",
"bootselector": "1",
"recentlyprogfw": "1",
"do_memtest": "0",
"memtest_pass": "idle",
"stdin": "serial",
"stdout": "serial",
"stderr": "serial",
"ethact": "ast_eth0",
"ethaddr": "6c:0b:84:81:ba:97",
"eth1addr": "6c:0b:84:81:ba:98"
},
"beginAddress": "0x00030000",
"endAddress": "0x00040000"
}
]
}
Сводим в файлик
partitions.json
{
"partitions": [
{
// uboot
"fileName": "10-boot.bin",
"beginAddress": "0x00000000",
"endAddress": "0x0002F198"
},
{
// uboot env
"fileName": "11-boot-env.bin",
"beginAddress": "0x00030000",
"endAddress": "0x00040000",
},
{
// mount as '/conf' (jffs2)
"fileName": "20-conf.bin",
"beginAddress": "0x00050000",
"endAddress": "0x000C0000"
},
{
// mount as '/bkupconf' (jffs2)
"fileName": "30-conf.bin",
"beginAddress": "0x000D0000",
"endAddress": "0x00140000"
},
{
// mount as '/' (uimage ramdisk)
"fileName": "40-root-header.bin",
"beginAddress": "0x00150000",
"endAddress": "0x01252040"
},
// Откуда инфо что это uimage header + cramfs? Это заметка от меня из будущего который уже посмотрел внутрь через binwalk
{
// mount as '/' (uimage header)
"fileName": "41-root-header.bin",
"beginAddress": "0x00150000",
"endAddress": "0x00150040"
},
{
// mount as '/' (uimage content (cramfs))
"fileName": "42-root-content.bin",
"beginAddress": "0x00150040",
"endAddress": "0x01252040"
},
{
// kernel (uimage)
"fileName": "50-osimage.bin",
"beginAddress": "0x01260040",
"endAddress": "0x0143A02C"
},
{
// mount as '/usr/local/www' (cramfs)
"fileName": "60-www.bin",
"beginAddress": "0x01450000",
"endAddress": "0x01670000"
},
{
// build info (string)
"fileName": "70-ast2400e.bin",
"beginAddress": "0x01FF0040",
"endAddress": "0x01FF00B4"
}
]
}
Разбираем бинарь
split
$ uefi-mod-tools bin split -i backup_rd450x_pve2_04-01-26.bin -t partitions.json -o backup_rd450x_pve2_04-01-26
[01:46:15 INF] Reading data from backup_rd450x_pve2_04-01-26.bin
[01:46:15 INF] Reading data from partitions.json
[01:46:15 INF] Saving backup_rd450x_pve2_04-01-26/10-boot.bin
[01:46:15 INF] Writing output to backup_rd450x_pve2_04-01-26/10-boot.bin
[01:46:15 INF] Saving backup_rd450x_pve2_04-01-26/11-boot-env.bin
[01:46:15 INF] Writing output to backup_rd450x_pve2_04-01-26/11-boot-env.bin
[01:46:15 INF] Saving backup_rd450x_pve2_04-01-26/20-conf.bin
[01:46:15 INF] Writing output to backup_rd450x_pve2_04-01-26/20-conf.bin
[01:46:15 INF] Saving backup_rd450x_pve2_04-01-26/30-conf.bin
[01:46:15 INF] Writing output to backup_rd450x_pve2_04-01-26/30-conf.bin
[01:46:15 INF] Saving backup_rd450x_pve2_04-01-26/40-root-header.bin
[01:46:15 INF] Writing output to backup_rd450x_pve2_04-01-26/40-root-header.bin
[01:46:15 INF] Saving backup_rd450x_pve2_04-01-26/41-root-header.bin
[01:46:15 INF] Writing output to backup_rd450x_pve2_04-01-26/41-root-header.bin
[01:46:15 INF] Saving backup_rd450x_pve2_04-01-26/42-root-content.bin
[01:46:15 INF] Writing output to backup_rd450x_pve2_04-01-26/42-root-content.bin
[01:46:15 INF] Saving backup_rd450x_pve2_04-01-26/50-osimage.bin
[01:46:15 INF] Writing output to backup_rd450x_pve2_04-01-26/50-osimage.bin
[01:46:15 INF] Saving backup_rd450x_pve2_04-01-26/60-www.bin
[01:46:15 INF] Writing output to backup_rd450x_pve2_04-01-26/60-www.bin
[01:46:15 INF] Saving backup_rd450x_pve2_04-01-26/70-ast2400e.bin
[01:46:15 INF] Writing output to backup_rd450x_pve2_04-01-26/70-ast2400e.bin
$ binwalk
$ find ./backup_rd450x_pve2_04-01-26/ -type f | sort | xargs -n 1 binwalk
/home/mixa3607/rd450x/backup_rd450x_pve2_04-01-26/10-boot.bin
------------------------------------------------------------------------------------------------------------------------
DECIMAL HEXADECIMAL DESCRIPTION
------------------------------------------------------------------------------------------------------------------------
152300 0x252EC CRC32 polynomial table, little endian
153604 0x25804 U-Boot version string: 1.1.6 (Nov 27 2018 -
15:34:08)
190368 0x2E7A0 CRC32 polynomial table, little endian
------------------------------------------------------------------------------------------------------------------------
Analyzed 1 file for 111 file signatures (251 magic patterns) in 3.0 milliseconds
Analyzed 1 file for 111 file signatures (251 magic patterns) in 2.0 milliseconds
/home/mixa3607/rd450x/backup_rd450x_pve2_04-01-26/20-conf.bin
------------------------------------------------------------------------------------------------------------------------
DECIMAL HEXADECIMAL DESCRIPTION
------------------------------------------------------------------------------------------------------------------------
320 0x140 JFFS2 filesystem, little endian, nodes: 792,
total size: 440976 bytes
------------------------------------------------------------------------------------------------------------------------
Analyzed 1 file for 111 file signatures (251 magic patterns) in 3.0 milliseconds
/home/mixa3607/rd450x/backup_rd450x_pve2_04-01-26/30-conf.bin
------------------------------------------------------------------------------------------------------------------------
DECIMAL HEXADECIMAL DESCRIPTION
------------------------------------------------------------------------------------------------------------------------
0 0x0 JFFS2 filesystem, little endian, nodes: 990,
total size: 458704 bytes
------------------------------------------------------------------------------------------------------------------------
Analyzed 1 file for 111 file signatures (251 magic patterns) in 4.0 milliseconds
/home/mixa3607/rd450x/backup_rd450x_pve2_04-01-26/40-root-header.bin
------------------------------------------------------------------------------------------------------------------------
DECIMAL HEXADECIMAL DESCRIPTION
------------------------------------------------------------------------------------------------------------------------
0 0x0 uImage firmware image, header size: 64 bytes,
data size: 17833984 bytes, compression: none,
CPU: ARM, OS: Linux, image type: RAMDisk Image,
load address: 0x0, entry point: 0x0, creation
time: 2016-12-19 08:06:55, image name: ""
------------------------------------------------------------------------------------------------------------------------
Analyzed 1 file for 111 file signatures (251 magic patterns) in 41.0 milliseconds
Analyzed 1 file for 111 file signatures (251 magic patterns) in 2.0 milliseconds
/home/mixa3607/rd450x/backup_rd450x_pve2_04-01-26/42-root-content.bin
------------------------------------------------------------------------------------------------------------------------
DECIMAL HEXADECIMAL DESCRIPTION
------------------------------------------------------------------------------------------------------------------------
0 0x0 CramFS filesystem, little endian, 2560 files,
total size: 17833984 bytes
------------------------------------------------------------------------------------------------------------------------
Analyzed 1 file for 111 file signatures (251 magic patterns) in 48.0 milliseconds
/home/mixa3607/rd450x/backup_rd450x_pve2_04-01-26/50-osimage.bin
------------------------------------------------------------------------------------------------------------------------
DECIMAL HEXADECIMAL DESCRIPTION
------------------------------------------------------------------------------------------------------------------------
0 0x0 uImage firmware image, header size: 64 bytes,
data size: 1941420 bytes, compression: none, CPU:
ARM, OS: Linux, image type: OS Kernel Image, load
address: 0x40008000, entry point: 0x40008000,
creation time: 2016-12-19 07:59:14, image name:
"Linux-2.6.28.10-ami"
------------------------------------------------------------------------------------------------------------------------
Analyzed 1 file for 111 file signatures (251 magic patterns) in 7.0 milliseconds
/home/mixa3607/rd450x/backup_rd450x_pve2_04-01-26/60-www.bin
------------------------------------------------------------------------------------------------------------------------
DECIMAL HEXADECIMAL DESCRIPTION
------------------------------------------------------------------------------------------------------------------------
0 0x0 CramFS filesystem, little endian, 740 files,
total size: 2191360 bytes
------------------------------------------------------------------------------------------------------------------------
Analyzed 1 file for 111 file signatures (251 magic patterns) in 7.0 milliseconds
Analyzed 1 file for 111 file signatures (251 magic patterns) in 2.0 milliseconds
Экстрактим секции
note
Всегда обращайте внимание на endianes при упаковке
UBoot
Это экзешник, можно залить в IDA PRO и поковырять так же тут можно запатчить cmdline ядра
UBoot env
Это страница такой структуры
Разбираем:
in backup_rd450x_pve2_04-01-26
$ uefi-mod-tools uboot env-read -i 11-boot-env.bin -o 11-boot-env.json
[00:25:47 INF] Reading data from 11-boot-env.bin
[00:25:47 INF] CRC32 hash matched
[00:25:47 INF] Read 15 pairs
[00:25:47 INF] Writing output to 11-boot-env.json
$ cat 11-boot-env.json
{
"size": 65536,
"paddingSize": 4,
"hash": 879708050,
"hashMatched": true,
"variables": {
"bootcmd": "bootfmh",
"bootdelay": "3",
"baudrate": "0x9600",
"loads_echo": "1",
"autoload": "no",
"bootselector": "1",
"recentlyprogfw": "1",
"do_memtest": "0",
"memtest_pass": "idle",
"stdin": "serial",
"stdout": "serial",
"stderr": "serial",
"ethact": "ast_eth0",
"ethaddr": "6c:0b:84:81:ba:97",
"eth1addr": "6c:0b:84:81:ba:98"
}
}
Добавляем/меняем/удаляем переменные и собраем обратно:
in backup_rd450x_pve2_04-01-26
$ uefi-mod-tools uboot env-write -i 11-boot-env.json -o 11-boot-env.bin
[00:29:22 INF] Reading data from 11-boot-env.json
[00:29:22 INF] Write 15 pairs
[00:29:22 INF] Writing output to 11-boot-env.bin
CramFS
Распаковка:
in backup_rd450x_pve2_04-01-26
$ mkdir /mnt/cramfs
$ sudo mount -t cramfs -o rw 60-www.bin /mnt/cramfs
$ mkdir 60-www
$ cp -a /mnt/cramfs/. 60-www
$ sudo umount /mnt/cramfs
Упаковка (не проверено):
in backup_rd450x_pve2_04-01-26
$ mkfs.cramfs -b 65536 -N little ./60-www ./60-www.bin
mkfs.cramfs: warning: gids truncated to 8 bits. (This may be a security concern.)
JFFS2
Распаковка:
in backup_rd450x_pve2_04-01-26
$ binwalk 30-conf.bin -d 30-conf -e
/home/mixa3607/rd450x/backup_rd450x_pve2_04-01-26/30-conf/30-conf.bin
---------------------------------------------------------------------------------------------
DECIMAL HEXADECIMAL DESCRIPTION
---------------------------------------------------------------------------------------------
0 0x0 JFFS2 filesystem,
little endian, nodes:
990, total size:
458704 bytes
---------------------------------------------------------------------------------------------
[+] Extraction of jffs2 data at offset 0x0 completed successfully
---------------------------------------------------------------------------------------------
Analyzed 1 file for 111 file signatures (251 magic patterns) in 239.0 milliseconds
$ ls 30-conf/30-conf.bin.extracted/0/jffs2-root/
BMC.conf dhcp.preip_4 ntp.conf snmpd.conf
BMC1 dhcp6c.conf ntp.stat ssh_host_dsa_key
Dev_GUID.dat dhcp6c_duid openLdapGroup.conf ssh_host_dsa_key.pub
Fwversion dns.conf pam_withunix ssh_host_rsa_key
InstanceLocations.txt dns.tmp pam_wounix ssh_host_rsa_key.pub
Preserve-AMI.ini hostname passwd sshd_config
Sys_GUID.dat hostname.conf phycfg.conf stunnel.conf
UpdateIptablesconf.sh hosts pwdEncKey syslog.conf
activedir.conf hosts.allow radius.conf.disabled timeouts
activeslave.conf hosts.deny radiuspriv.ini uartroute_BMC.conf
adjtime hpm.conf resolv.conf uartroute_SOL.conf
adviserd.conf interfaces rmedia.conf uartroute_SYS.conf
autorecord.conf iptables.conf rotate.conf user_home
backup_cfg_list-AMI.ini ldap.conf rsyslog.conf usermacro.conf
bond.conf license rt_tables vlaninterfaces
compbook localtime shadow vlansetting.conf
console_tty mountall_dual.sh singleport.conf vmedia.conf
crontab ncml.conf snmp
dcmi.conf ncsicfg.conf snmp_users.conf
default_sh nsswitch.conf snmpcfg.conf
Упаковка (не проверено):
in backup_rd450x_pve2_04-01-26
$ sudo mkfs.jffs2 -d 30-conf/30-conf.bin.extracted/0/jffs2-root/ -e 65536 -o 30-conf.mod.bin --little-endian -v
...
Compression mode: priority
Compressors:
none compr: 45 blocks (1344) decompr: 0 blocks
lzo (prio:80) - compr: 0 blocks (0/0) decompr: 0 blocks
zlib (prio:60) + compr: 300 blocks (83844/307813) decompr: 0 blocks
rtime (prio:50) + compr: 1 blocks (2/3) decompr: 0 blocks
Compression errors: 0
build info (string)
Это просто строка с билд инфой
in backup_rd450x_pve2_04-01-26
$ cat 70-ast2400e.bin
FW_VERSION=3.24.4421
FW_DATE=Dec 19 2016
FW_BUILDTIME=16:07:05 CST
FW_DESC=RR8 AST2400 HWENC BUILD 2
FW_PRODUCTID=1
Собираем всё обратно
Перетираем партишены в родном дампе по очереди в которой они в partitions.json
$ uefi-mod-tools bin combine -i backup_rd450x_pve2_04-01-26.bin -t partitions.json -p backup_rd450x_pve2_04-01-26 -o bac
kup_rd450x_pve2_04-01-26.mod.bin
[01:54:30 INF] Reading data from backup_rd450x_pve2_04-01-26.bin
[01:54:30 INF] Reading data from partitions.json
[01:54:30 INF] Injecting backup_rd450x_pve2_04-01-26/10-boot.bin
[01:54:30 INF] Reading data from backup_rd450x_pve2_04-01-26/10-boot.bin
[01:54:30 INF] Injecting backup_rd450x_pve2_04-01-26/11-boot-env.bin
[01:54:30 INF] Reading data from backup_rd450x_pve2_04-01-26/11-boot-env.bin
[01:54:30 INF] Injecting backup_rd450x_pve2_04-01-26/20-conf.bin
[01:54:30 INF] Reading data from backup_rd450x_pve2_04-01-26/20-conf.bin
[01:54:30 INF] Injecting backup_rd450x_pve2_04-01-26/30-conf.bin
[01:54:30 INF] Reading data from backup_rd450x_pve2_04-01-26/30-conf.bin
[01:54:30 INF] Injecting backup_rd450x_pve2_04-01-26/40-root-header.bin
[01:54:30 INF] Reading data from backup_rd450x_pve2_04-01-26/40-root-header.bin
[01:54:30 INF] Injecting backup_rd450x_pve2_04-01-26/41-root-header.bin
[01:54:30 INF] Reading data from backup_rd450x_pve2_04-01-26/41-root-header.bin
[01:54:30 INF] Injecting backup_rd450x_pve2_04-01-26/42-root-content.bin
[01:54:30 INF] Reading data from backup_rd450x_pve2_04-01-26/42-root-content.bin
[01:54:30 INF] Injecting backup_rd450x_pve2_04-01-26/50-osimage.bin
[01:54:30 INF] Reading data from backup_rd450x_pve2_04-01-26/50-osimage.bin
[01:54:30 INF] Injecting backup_rd450x_pve2_04-01-26/60-www.bin
[01:54:30 INF] Reading data from backup_rd450x_pve2_04-01-26/60-www.bin
[01:54:30 INF] Injecting backup_rd450x_pve2_04-01-26/70-ast2400e.bin
[01:54:30 INF] Reading data from backup_rd450x_pve2_04-01-26/70-ast2400e.bin
[01:54:30 INF] Saving backup_rd450x_pve2_04-01-26.mod.bin
[01:54:30 INF] Writing output to backup_rd450x_pve2_04-01-26.mod.bin
Final words
Если вам повезёт и ничего не сломалось, то таким образом можно аккуратно поправить BMC прошивку, а если трогать только UBoot env для восстановления MACов, то шанс на успех 99%.
